Food and Beverage Pure Water Treatment Equipment
Requirements for water treatment equipment in the food and beverage industry
The water used in the food and beverage industry usually requires softened water or purified water, and the conductivity is usually below 10uS/cm. It needs to comply with "GB5749-2006 Hygienic Standard for Drinking Water", "CJ94-1999 Standard for Purification of Drinking Water", and "GB 17324-2003" "Hygienic Standards for Purified Water in Drinking Bottles (Buckets)" related standards.
Food and beverage pure water treatment machine
With the improvement of food safety awareness, the food and beverage industry is paying more and more attention to the quality of pure water. Pure water means no impurities, sterile viruses, suspended solids, and soluble salts. Organic and inorganic pollutants are removed through various physical and chemical means. Comply with industry standards, meet the needs of processed water and food production, and ensure that food hygiene supervision meets regulatory requirements.
Advantages
The characteristics of pure water processing machine are that it is extremely pure, sweet and mellow, meets hygienic standards, and can be drunk without boiling. Pure water is prepared using methods such as distillation, deionization, ion exchange, and reverse osmosis.
Application
Ultra-pure water purification system is widely used in domestic water, industrial production water, medical and health water, food and beverage winery water, agricultural production water, electroplating coating water, electronic power water, textile and paper water, etc.
| Product water quality | GB / T6682-2008 laboratory water standard |
| Product model | CJ-ROU(300-1500)-EDI |
| Water production | 300-1500L/H |
| Water tank storage capacity | 200-1000L |
| Input power | <5Kw |
| Input voltage | AC380V |
| Water quality | ≤0.1μs/cm |
| RO removal rate | ≥99% |
| Heavy metals | <0.01PPb |
| Fragment particles | <1/ml |
Different specifications
can be customized according to customers' water needs.
| Product number | Water production
(L/H25℃) | Water quality(μs/cm) | Voltage power (KW) | Operating pressure
(Mpa) | Product Size
(MM) |
| CJ-ROU-300 | ≥300L/H | ≤0.1 | 380V/3.0 | 0.8-1.35 | 1500*700*1700 |
| CJ-ROU-600 | ≥600L/H | ≤0.1 | 380V/3.5 | 0.8-1.35 | 1500*700*1700 |
| CJ-ROU-1000 | ≥1000L/H | ≤0.1 | 380V/3.8 | 0.8-1.35 | 1500*700*1700 |
| CJ-ROU-1500 | ≥1500L/H | ≤0.1 | 380V/4.2 | 0.8-1.35 | 1750*750*1700 |
| CJ-ROU-300EDI | ≥300L/H | ≤0.1 | 380V/3.5 | 0.8-1.35 | 1500*700*1700 |
| CJ-ROU-600EDI | ≥600L/H | ≤0.1 | 380V/4.0 | 0.8-1.35 | 1500*700*1700 |
| CJ-ROU-1000EDI | ≥1000L/H | ≤0.1 | 380V/4.5 | 0.8-1.35 | 1500*700*1700 |
| CJ-ROU-1500EDI | ≥1500L/H | ≤0.1 | 380V/5.0 | 0.8-1.35 | 1750*750*1700 |
Biopharmaceutical pure water treatment equipment-process flow
The pretreatment filter element of ultrapure water equipment can effectively remove chlorine and organic pollutants in raw water, while the reverse osmosis membrane element further removes fine impurities and ions in the water, including salt and a small amount of bacteria. The final precision filtration is designed to improve water quality and effectively inhibit the growth of bacteria in the water.
